3-in-1 Airpower Line - 12 Feet
3-in-1 trailer connection assembly, 12 ft. Two air brake lines and a 7-way electrical cable in a single spiral-wrapped assembly.
Applications
Product Details
Description
- Product: 3-in-1 Airpower Line
- Length: 12 ft
- Configuration: 2 air lines + 1 electrical cable, spiral wrapped
- Electrical connector: 7-pin, SAE J560
- Air fitting: 1/2 in, with handle
- Air line I.D.: 3/8 in
- Working pressure: 225 psi
- Operating temperature: -55°F to 190°F (-48°C to 87°C)
- Fitting material: Brass and metal
- Jacket / hose material: PVC and rubber
- Cable construction: SAE J2394 1/8-2/10-4/12 — 8 AWG ground; 10 AWG red and blue; 12 AWG lamp circuits
- Standards: SAE J560 (connector), SAE J2394 (ABS power cable), SAE J1402 Type A and FMVSS 106 (air brake hose)
- Included: Clamp, snap clip and hanging bracket
- Warranty: 2 years
The SAE J2394 construction carries a 10 AWG blue conductor sized for continuous ABS primary power. The superseded SAE J1067 construction ran blue at 12 AWG and was not built to supply ABS, so confirm cable construction and not just conductor count when comparing assemblies.
Product Attributes
Technical Specifications
OEM Cross-Reference & Interchange Numbers
SPNA_3in1_12_H is a direct cross-reference replacement for the following OEM and competitor part numbers. Use these interchange numbers to confirm the equivalent before ordering:
